Suresh Indu Lasers Pvt Ltd

Fiber Laser Cutting Machine Flexi

Fiber Laser Cutting Machine Flexi
Price : 35 Lac / pieceGet Best Price

MOQ : 1 piece

Business Type Manufacturer, Exporter, Supplier, Retailer
Laser Source IPG / SIL OEM
Motor X 3050 mm SIL Brand
Motor XI 3050 mm SIL Brand
Click to view more

Preferred Buyer From

Location India ( Andhra Pradesh, Bihar, Chandigarh, Delhi, Goa, Gujarat, Haryana, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Punjab, Rajasthan, Tamil Nadu, Telangana, Uttar Pradesh only) & All other countries

Product Details

Motor Y
1520 mm SIL Brand
Z Axis
150 mm
Z Axis with Dual Pallet
220 mm
Cutting Head
Raytools Auto-Focus
CNC Controller
Cypcut
Rack & Pinion
SIL Brand
Electronic Pressure Regulator
30 Bar SMC
Gas Line & Filter
SMC
Gearbox
SIL Brand
LM Rails X, Y
SIL Brand
Chiller
Tongfie / SIL
Acceleration
0.8 G
Position Accuracy
≤ ± 0.05 mm / m
Repositioning Accuracy
≤ ± 0.03 mm
Maximum Rapid Speed
80 Meters / Min
Cutting Speed
20 Meters / Min
Dual Pallet
(Optional)
Product PDF

SIL Fiber Laser Metal Cutting Machine – Flexi model 3015 size with laser power of 1000 W or 1500 W power. It can cut Mild Steel, Stainless Steel, Coated Stainless Steel, and High-Strength steel, Aluminium, Brass, and Nickel easily.



The machine features a durable rack-and-pinion motion system, lightweight gantry with synchronized dual servo motors. Fiber Laser energy saves up to 70 percent as compared with traditional CO2 laser cutters, It can provide cutting speed to 20 m / min and rapid speed of 80 m/ min with 0.8 G acceleration.



Features:

  • Designed to work in harsh conditions.
  • All mechanics designed for more than 20 years life.
  • Cut part accuracy +/- 50 micron.
  • Machine up time more than 90%.
  • Best Service support from Highly Experienced Engineers.
  • Backup Laser source within warranty and post warranty.
  • Best Application support.
  • Service cost < 3% per annul.
  • Strong welded base frame.
  • Special Grade Material thick plate for mounting Linear Guide and Rack.
  • Light weight Gantry for High dynamics.
  • Original SIL brand Linear guides and Block.
  • Low backlash Gearbox from SIL brand.
  • Fire proof Bellow for protection.
  • New Generation Control System.
  • SIL brand CNC controller.
  • SIL brand Motor Drives.
  • Acceleration 0.8 G.
  • IPG laser source.
  • Single Pallet Table. (Option of Dual Pallet).
  • Cutting Speeds up to 20 meters/min.
  • Rapids up to 80 meters/min.
  • 150 mm Z stroke giving more clear space for stationary pallet.
  • Control panel: All switch gears from Siemens, Isolated HV protected specially build to work in Harsh Electrical conditions
